| Standard specifications: |
Unwinder：
|
| 1. |
Effective film thickness: 0.010-0.050(mm) |
| 2. |
Effective unwinding width: 300-500(mm) |
| 3. |
Effective unwinding diameter: 450mm |
| 4. |
Paper tube inner diameter: 3" (76.0 mm) |
Rewinder：
|
| 1. |
Single-shaft rewinding |
| 2. |
Effective rewinding width: 300-500(mm) |
| 3. |
Effective rewinding diameter: 175mm |
| 4. |
Paper tube inner diameter: 2"、3" |
| 5. |
Options: Diameter 2.0" (50.4mm) rewinding jack clamp |
| Power： |
| 1. |
Power：Available on request |
| 2. |
Main Motor：5.0HP |
| 3. |
Unwinder edge adjusting motor：0.5hp |
| 4. |
Air pressure：6.0 kgs/60 liters/min. |
| 5. |
Max. rewinding speed: 500-1500 M/min |
| 6. |
1650﹙L﹚x 1620﹙W﹚x 1850﹙H﹚(mm) |
