| General Specification |
| 1. |
Effective Printing Width：144mm. |
| 2. |
Effective Printing Colors：2 Colors printing. |
| 3. |
Effective Printing Length：Rubber relief Printing plate length (Max：250㎜) |
| 4. |
Suitable slitting specification：12, 24, 48mm. |
| 5. |
Slitting Length Setting：999M, 2- phases setting. |
| 6. |
Power Source：4.2KVA, 220V, ﹙50/60Hz﹚ |
| 7. |
Speed：120m/m |
| 8. |
Auto Temperature Control：40～80℃ |
| 9. |
Suitable Material：BOPP Adhesive Tape |
| Equipment Specification |
| 10. |
Unwinding Roller：
1)、Effective Unwinding Diameter：∮350mm
2)、Suitable inner diameter of paper tube：∮76mm.
|
| 11. |
Printing：
1)、 Suitable Rubber Plate Thickness：2.54mm.
2)、 Suitable Double Side Tape thickness：0.12mm.
3)、 Printing Colors：２ colors.
|
| 12. |
Drying：
1)、Fan Blower：120w * 1 set.
2)、Electric heater：360w * 1 set. |
| 13. |
Slitting：
1)、Blade by slitter：22 * 60 * 0.2 mm *15 pic.
2)、Edge case by slitter：48mm *3 set.
|
| 14. |
Rewinding：
1)、Turret Rewinder：Reverse & Change roller of Turret roller.
2)、Effective Rewinding Diameter：MAX ∮ 140㎜
3)、Suitable inner diameter of Paper Tube：∮76mm.
|
