| General Specification: |
| 1. |
Coating & Drying speed：40～180 m/min |
| 2. |
Effective Coating Width：1000～2000mm (Optional) |
| 3. |
Applicable Material Diameter：Ø 200～1000mm |
| 4. |
Applicable Material：
| (1) |
Hard films 0.02～0.10mm |
| (2) |
Soft films 0.05～0.20mm |
| (3) |
Paper 40～250 g/m2 |
|
| 5. |
Applicable adhesives：
| (1) |
Acrylic Solvent Base |
| (2) |
Water Base Adhesive Glue |
| (3) |
Rubber Adhesive |
| (4) |
Solvent、Water-Based primary adhesives release (silicon) |
|
| 6. |
Adhesive Coating Types：
| (1) |
Doctor coating |
| (2) |
Comma-Roll direct coating |
| (3) |
Reverse coating |
| (4) |
Maya Bar coating |
| (5) |
Gravure Die coating |
|
| 7. |
Controllable Adhesive Coating Thickness：0.020㎜～0.10㎜ |
| 8. |
Even Coating Thickness：±0.0015㎜ |
| 9. |
Drying & Heating Methods：
| (1) |
Gas Heating，Blow drying |
| (2) |
Indirect Steam Heating，Blow Drying |
| (3) |
Indirect Thermo Oil Heating，Blow Drying |
| (4) |
Indirect Electro Heating，Blow Drying |
|
| 10. |
Automatic temperature control：70～150°C |
| 11. |
Unwinding Types：
| (1) |
Single Shaft Rewinder |
| |
Passive unwinding |
| (2) |
Turret Rewinder |
| |
Passive unwinding |
| |
Active unwinding |
|
| 12. |
Rewinding Types：
| (1) |
Turret Rewinder |
| (2) |
Single Shaft Rewinder |
|
| 13. |
Auto-connection system：
| (1) |
Turret unwinder |
| (2) |
Non-stop & Non-deceleration，auto connecting (optional) |
|
| 14. |
Tension Control Methods：Manual、 Semi-Automatic、 Fully Automatic |
| 15. |
Power：220V，380V, 415V, 440V, 50/60Hz (optional) |
